Ultra Smart 8 MP ColorVu Fixed Turret Network Camera Support Face Capture, IP67 protection,DS-2CD2387G2-LU

DS-2CD2387G2-LU 8 MP ColorVu Fixed Turret Network Camera

• High quality imaging with 8 MP resolution
• Efficient H.265+ compression technology
• Clear imaging against strong backlight due to 130 dB WDR technology
• Built-in microphone for real-time audio security(-U)
• Focus on human and vehicle targets classification based on deep learning
• 24/7 colorful imaging
• Water and dust resistant (IP67)

Camera

• Image Sensor :     1/1.2″ Progressive Scan CMOS
• Max. Resolution :   3840 × 2160
• Min. Illumination :    Color : 0.0005 Lux @ (F1.0, AGC ON)
• Shutter Speed : 1/3 s to 1/100,000 s
• Day & Night : 24/7 Color imaging
• Angle Adjustment : Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Lens

• Lens Type :      Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV :    2.8 mm, horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124°; 4 mm, horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°
• Lens Mount :   M16
• Iris Type :         Fixed
• Aperture:         F1.0
• Depth Of Field :    2.8 mm: 3.1 m to ∞   ;  4 mm: 3.6 m to ∞

DORI

• DORI:  2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 9 m; 4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m

Illuminator

• Supplement Light :   TypeWhite Light
• Supplement Light :   RangeUp to 30 m
• Smart Supplement Light :  Yes

Video

• Main Stream :  50 Hz:   25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)  ;  60 Hz:   24 fps (3840 × 2160)     30 fps (3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream ：50 Hz: 25 fps (640 × 480, 640 × 360)  ;  60 Hz: 30 fps (640 × 480, 640 × 360)
• Third Stream ： 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)  ;  60 Hz: 10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)
• Video Compression ： Main stream: H.265/H.264/H.264+/H.265+  ;  Sub-stream: H.265/H.264/MJPEG  ;  Third stream: H.265/H.264
• Video Bit Rate ： 32 Kbps to 16 Mbps
• H.264 Type ： Baseline Profile/Main Profile/High Profile
• H.265 Type ： Main Profile
• Bit Rate Control ： CBR/VBR
• Scalable Video Coding (SVC) ：H.264 and H.265 encoding
• Region Of Interest (ROI) ：1 fixed region for main stream and sub-stream

Network

• Simultaneous Live View ： Up to 6 channels
• API ： Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK , ISUP
• Protocols ： TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP,SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
• User/Host ： Up to 32 users. 3 user levels: administrator, operator and user
• Security ： Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
• Network Storage ： NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• Client ： iVMS-4200, Hik-Connect, Hik-Central
• Web Browser ： Plug-in required live view: IE 10, IE 11  ;  Plug-in free live view : Chrome 57.0+, Firefox 52.0+ ; Local service: Chrome 57.0+, Firefox 52.0+


• Wide Dynamic Range (WDR) ： 130 dB
• Privacy Mask ： 8 programmable polygon privacy masks, mask color or mosaic configurable
• Day/Night Switch ： Day, Night, Auto, Schedule
• Image Enhancement ： BLC, HLC, 3D DNR
• Image Parameters Switch ： Yes
• Image Settings ： Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
• adjustable by client software or web browser

Interface

•   Ethernet Interface ： 1 RJ45 10 M/100 M self-adaptive Ethernet port
•   On-Board Storage ： Built-in memory card slot, support microSD/SDHC/SDXC/TF card, up to 256 GB
•   Built-In Microphone-LU: Yes

Event

•   Basic Event ： Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering  alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
•   Smart Event ： Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)) Scene change detection
•   Linkage ： Upload to NAS/memory card/FTP, notify surveillance center, trigger record, trigger capture, send email

Deep Learning Function

• Face Capture ： Yes

General

• Power : -L: 12 VDC, 0.42 A, max. 5 W      PoE: 802.3af, 36 V to 57 V, 0.17 A to 0.11 A, max. 6.0 W ;  -LU: 12 VDC, 0.46 A, max. 5.5 W    PoE: 802.3af, 36 V to 57 V, 0.18 A to 0.11 A, max. 6.5 W
• Material : Cover: metal, main body: metal
• Dimension : Ø138.3 mm × 120.1 mm (Ø5.4″ × 4.7″)
• Package Dimension : 170 mm × 170 mm × 150 mm (6.7″ × 6.7″ × 5.9″) ​Approx. 870 g (1.9 lb.)
• With Package Weight : Approx. 1160 g (2.6 lb.)
• Storage Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup And Operating Conditions ： -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language ： 33 languages : English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
• General Function ： Anti-flicker, heartbeat, mirror, password reset via e-mail, pixel counter
• Software Reset ： Yes

Approval

• EMC ： FCC (47 CFR Part 15, Subpart B)  ；CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN50130-4: 2011+A1: 2014)  ；RCM (AS/NZS CISPR 32: 2015) ；IC (ICES-003: Issue 7) ；KC (KN32: 2015, KN35: 2015)
• Safety ： UL (UL 62368-1) ；CB (IEC 62368-1: 2014+A11) ；CE-LVD (EN 62368-1: 2014/A11: 2017)
• Environment ： CE-RoHS (2011/65/EU) ；WEEE (2012/19/EU) ；Reach (Regulation (EC) No 1907/2006)
• Protection : IP67: IEC 60529-2013
